Twisted In Wire Brush

  • Custom & standard twisted-in-wire brushes
  • Many styles and materials available in-stock
  • Twisted brushes for power or hand use
  • Twisted brushes for cleaning, deburring, polishing reaming and blending

Twisted in Wire Brushes

Product Specification:-

In twisted-in-wire brushes, the filament material is twisted between two wires. This type of brush is primarily used to clean the internal walls of pipes.

Like all other Brush India brushes there is a wide range of possible filament types. The middle of the brush consists of what is called the ‘soul’, which is usually made of two twisted wires. The thickness of the twisted wires can vary. It determines the strength as well as the fill density of the brush.

Types of Spiral

SINGLE SPIRAL Your choice of fill bristles are twisted between two (2) stem wires

SINGLE SPIRAL - DOUBLE STEM Your choice of fill bristles are twisted between four (4) stem wires

DOUBLE SPIRAL – DOUBLE STEM Two (2) layers of your choice of fill bristles are twisted between four (4) stem wires.

Types of Material

  • Carbon Steel
  • Non-Ferrous
  • Stainless Steel
  • Synthetic Fibers
  • Animal Fibers
  • Vegetable Fibers

Non-Ferrous Wire
Aluminum, copper, phosphor bronze brass, nickel, silver.

Brass Wire
Rust-proof and spark resistant, brass provides gentle brushing action.

Phosphor Bronze Wire
Similar to brass with better shape retention

Carbon Steel Wire
Typically used in applications where abrasion is required in dry environments. High carbon is utilized for deep cutting where aggressive abrasion is required.

Stainless Steel Wire
Rust-proof and strong and ideal for applications that involve stainless steel or aluminum. Will not leave ferrous deposits.

Oil Tempered Wire (Flat Wire)
Flat wire is the most aggressive brushing material available.

Crimped or Straight?
A crimped, or wavy, bristle extends the life of the brush and is ideal for abrasive cleaning. Straight bristles are softer and more flexible.
